TYPE-C socket TYPE-C female connector side-entry interface – GSC-TYP-0107
Type C14 PinSMTRight Angle
GSC-TYP-0107 is a type C 14-contact connector, 11.62×10×4mm, side-entry, 14-pin (surface-mount type), Type-C connector. GSCONN part GSC-TYP-0107.
Surface MountSMT termination
10,000 CyclesRated mating life
14 PinContact count
Technical Specifications
| Series | TYPE-C JACKES |
| Type | Side Entry / 14P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 5–20 N |
Key Features
- 11.62×10×4mm
- side‑entry
- 14‑pin (surface‑mount type)
- Type‑C connector
Applications
- Consumer electronics
- Docking stations and USB hubs
- Charging and power delivery devices
- Industrial HMI and control panels
Drawing & Dimensions
GSC-TYP-0107 is a type C 14-contact connector, 11.62×10×4mm, side-entry, 14-pin (surface-mount type), Type-C connector.
| Series | TYPE-C JACKES |
|---|---|
| Type | Side Entry / 14P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 5–20 N |
