TYPE-C socket TYPE-C female connector TYPE-C 16-pin interface – GSC-TYP-0120

Name: TYPE-C socket TYPE-C female connector TYPE-C 16-pin interface – GSC-TYP-0120
Brand: GSCONN

Type C16 PinSMTRight Angle

Tags:

#16 Pin #PCB #Receptacle #Right Angle #SMT #USB Connector #USB Type-C

GSC-TYP-0120 is a type C 16-contact connector, 8.94 × 7.35 mm, horizontal, front-insertion, rear-surface-mount, 16-pin (surface-mount type) Type-C connector. GSCONN part GSC-TYP-0120.

Request a Quote → Download Datasheet

Surface MountSMT termination

16 PinContact count

Technical Specifications

Series	TYPE-C JACKETS
Type	Front-insert, rear-attach / 16P
Mating cycles	5,000
Insertion / Removal force	5–20 N

Key Features

8.94 × 7.35 mm
horizontal
front-insertion
rear-surface-mount
16-pin (surface-mount type) Type-C connector

Applications

Consumer electronics
Docking stations and USB hubs
Charging and power delivery devices
Industrial HMI and control panels

Drawing & Dimensions

GSC-TYP-0120 is a type C 16-contact connector, 8.94 × 7.35 mm, horizontal, front-insertion, rear-surface-mount, 16-pin (surface-mount type) Type-C connector.
