GSC-TYP-0146 is a type C connector, vertical TYPE-C & USB 2.0 Combo, Single-Sided Plug (Board-Mount Type), Two-in-One Interface. GSCONN part GSC-TYP-0146.

Request a Quote → Download Datasheet
10,000 CyclesRated mating life

Technical Specifications

SeriesTYPE-C JACKES
TypeTYPE-C & USB 2.0
Mating cycles10,000 cycles
Insertion / Removal force5–20 N

Key Features

  • Vertical TYPE‑C & USB 2.0 Combo
  • Single‑Sided Plug (Board‑Mount Type)
  • Two‑in‑One Interface

Applications

  • Consumer electronics
  • Docking stations and USB hubs
  • Charging and power delivery devices
  • Industrial HMI and control panels
Drawing & Dimensions
TYPE-C socket TYPE-C female connector TYPE-C combo interface – GSC-TYP-0146 drawing

GSC-TYP-0146 is a type C connector, vertical TYPE-C & USB 2.0 Combo, Single-Sided Plug (Board-Mount Type), Two-in-One Interface.

Series TYPE-C JACKES
Type TYPE-C & USB 2.0
Mating cycles 10,000 cycles
Insertion / Removal force 5–20 N

Downloads

Technical DrawingPDF · 87 KB
