TYPE-C socket TYPE-C female connector TYPE-C interface – GSC-TYP-0118
Type C16 PinSMTRight Angle
GSC-TYP-0118 is a type C 16-contact connector, 8.94×8.35×3.21 mm, horizontal, 16-pin (surface-mount), Type-C connector. GSCONN part GSC-TYP-0118.
Surface MountSMT termination
10,000 CyclesRated mating life
16 PinContact count
Technical Specifications
| Series | TYPE-C JACKES |
| Type | Universal / 16P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 5–20 N |
Key Features
- 8.94×8.35×3.21 mm
- horizontal
- 16-pin (surface-mount)
- Type-C connector
Applications
- Consumer electronics
- Docking stations and USB hubs
- Charging and power delivery devices
- Industrial HMI and control panels
Drawing & Dimensions
GSC-TYP-0118 is a type C 16-contact connector, 8.94×8.35×3.21 mm, horizontal, 16-pin (surface-mount), Type-C connector.
| Series | TYPE-C JACKES |
|---|---|
| Type | Universal / 16P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 5–20 N |
