TYPE-C socket TYPE-C female connector TYPE-C interface – GSC-TYP-0119
Type C16 PinSMTRight Angle
GSC-TYP-0119 is a type C 16-contact connector, 9.47×8×5.91 mm, horizontal, raised-height version, 16-pin (surface-mount type), Type-C connector. GSCONN part GSC-TYP-0119.
Surface MountSMT termination
10,000 CyclesRated mating life
16 PinContact count
Technical Specifications
| Series | TYPE-C JACKES |
| Type | Raised model / 16P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 5–20 N |
Key Features
- 9.47×8×5.91 mm
- horizontal
- raised‑height version
- 16‑pin (surface‑mount type)
- Type‑C connector
Applications
- Consumer electronics
- Docking stations and USB hubs
- Charging and power delivery devices
- Industrial HMI and control panels
Drawing & Dimensions
GSC-TYP-0119 is a type C 16-contact connector, 9.47×8×5.91 mm, horizontal, raised-height version, 16-pin (surface-mount type), Type-C connector.
| Series | TYPE-C JACKES |
|---|---|
| Type | Raised model / 16P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 5–20 N |
