TYPE-C socket TYPE-C female connector TYPE-C interface – GSC-TYP-0135
Type C6 PinSMT
GSC-TYP-0135 is a type C 6-contact connector, 8.94×6.8×3.16 mm, universal type, 6P (surface-mount), Type-C connector. GSCONN part GSC-TYP-0135.
Surface MountSMT termination
10,000 CyclesRated mating life
6 PinContact count
Technical Specifications
| Series | TYPE-C JACKES |
| Type | Universal / 6P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 0.5–2.0 kgf |
Key Features
- 8.94×6.8×3.16 mm
- universal type
- 6P (surface-mount)
- Type-C connector
Applications
- Consumer electronics
- Docking stations and USB hubs
- Charging and power delivery devices
- Industrial HMI and control panels
Drawing & Dimensions
GSC-TYP-0135 is a type C 6-contact connector, 8.94×6.8×3.16 mm, universal type, 6P (surface-mount), Type-C connector.
| Series | TYPE-C JACKES |
|---|---|
| Type | Universal / 6P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 0.5–2.0 kgf |
