GSC-TYP-0136 is a type C 6-contact connector, 8.94×6.8×3.16 mm, horizontal, general-purpose, 6P (surface-mount), Type-C connector. GSCONN part GSC-TYP-0136.

Request a Quote → Download Datasheet
Surface MountSMT termination
3,000 CyclesRated mating life
6 PinContact count

Technical Specifications

SeriesTYPE-C JACKES
TypeUniversal / 6P
Mating cycles3,000 cycles
Insertion / Removal force5–20 N

Key Features

  • 8.94×6.8×3.16 mm
  • horizontal
  • general-purpose
  • 6P (surface-mount)
  • Type-C connector

Applications

  • Consumer electronics
  • Docking stations and USB hubs
  • Charging and power delivery devices
  • Industrial HMI and control panels
Drawing & Dimensions
TYPE-C socket TYPE-C female connector TYPE-C interface – GSC-TYP-0136 drawing

GSC-TYP-0136 is a type C 6-contact connector, 8.94×6.8×3.16 mm, horizontal, general-purpose, 6P (surface-mount), Type-C connector.

Series TYPE-C JACKES
Type Universal / 6P
Mating cycles 3,000 cycles
Insertion / Removal force 5–20 N

Downloads

Technical DrawingPDF · 61 KB
