TYPE-C socket TYPE-C female connector TYPE-C interface – GSC-TYP-0137

TYPE-C socket TYPE-C female connector TYPE-C interface – GSC-TYP-0137

Type C14 PinThrough-HoleVertical
Tags:
#14 Pin#DIP#PCB#Receptacle#USB Connector#USB Type-C#Vertical
Share:LinkedInFacebookXWhatsAppEmail

GSC-TYP-0137 is a type C 14-contact connector, 10×8.94×3.16 mm, vertical, 14-pin (board-mounted plug-in type), Type-C connector. GSCONN part GSC-TYP-0137.

Request a Quote → Download Datasheet
Through-HolePCB solder termination
10,000 CyclesRated mating life
14 PinContact count

Technical Specifications

SeriesTYPE-C JACKES
TypeVertical plug-in / 14P
Mating cycles10,000 cycles
Insertion / Removal force5–20 N

Key Features

  • 10×8.94×3.16 mm
  • vertical
  • 14-pin (board-mounted plug-in type)
  • Type-C connector

Applications

  • Consumer electronics
  • Docking stations and USB hubs
  • Charging and power delivery devices
  • Industrial HMI and control panels
Drawing & Dimensions
TYPE-C socket TYPE-C female connector TYPE-C interface – GSC-TYP-0137 drawing

GSC-TYP-0137 is a type C 14-contact connector, 10×8.94×3.16 mm, vertical, 14-pin (board-mounted plug-in type), Type-C connector.

Series TYPE-C JACKES
Type Vertical plug-in / 14P
Mating cycles 10,000 cycles
Insertion / Removal force 5–20 N

Downloads

Technical DrawingPDF · 69 KB
