GSC-TYP-0138 is a type C 16-contact connector, 8.94×7.96×3.16 mm, 0.75 mm thick board, 16 pins (surface-mount type), Type-C connector. GSCONN part GSC-TYP-0138.

Request a Quote → Download Datasheet
Surface MountSMT termination
10,000 CyclesRated mating life
16 PinContact count

Technical Specifications

SeriesTYPE-C JACKES
Type0.75 mm thick board / 16P
Mating cycles10,000 cycles
Insertion / Removal force0.5–2.0 kgf

Key Features

  • 8.94×7.96×3.16 mm
  • 0.75 mm thick board
  • 16 pins (surface-mount type)
  • Type-C connector

Applications

  • Consumer electronics
  • Docking stations and USB hubs
  • Charging and power delivery devices
  • Industrial HMI and control panels
Drawing & Dimensions
TYPE-C socket TYPE-C female connector TYPE-C interface – GSC-TYP-0138 drawing

GSC-TYP-0138 is a type C 16-contact connector, 8.94×7.96×3.16 mm, 0.75 mm thick board, 16 pins (surface-mount type), Type-C connector.

Series TYPE-C JACKES
Type 0.75 mm thick board / 16P
Mating cycles 10,000 cycles
Insertion / Removal force 0.5–2.0 kgf
