TYPE-C socket TYPE-C female connector TYPE-C interface – GSC-TYP-0149
Type C24 PinSMT
GSC-TYP-0149 is a type C 24-contact connector, 8.94×7.9×3.16 mm, fixed terminal, H=0.5 & 1.9, 24P (surface-mount type), Type-C connector. GSCONN part GSC-TYP-0149.
Surface MountSMT termination
10,000 CyclesRated mating life
24 PinContact count
Technical Specifications
| Series | TYPE-C JACKES |
| Type | H=0.5&1.9 / 24P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 5–20 N |
Key Features
- 8.94×7.9×3.16 mm
- fixed terminal
- H=0.5 & 1.9
- 24P (surface-mount type)
- Type-C connector
Applications
- Consumer electronics
- Docking stations and USB hubs
- Charging and power delivery devices
- Industrial HMI and control panels
Drawing & Dimensions
GSC-TYP-0149 is a type C 24-contact connector, 8.94×7.9×3.16 mm, fixed terminal, H=0.5 & 1.9, 24P (surface-mount type), Type-C connector.
| Series | TYPE-C JACKES |
|---|---|
| Type | H=0.5&1.9 / 24P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 5–20 N |
