TYPE-C socket TYPE-C female connector TYPE-C interface – GSC-TYP-0151

TYPE-C socket TYPE-C female connector TYPE-C interface – GSC-TYP-0151

Type C24 Pin
Tags:
#24 Pin#Receptacle#USB Connector#USB Type-C
Share:LinkedInFacebookXWhatsAppEmail

GSC-TYP-0151 is a type C 24-contact connector, 9.85×9.87×3.16 mm, universal type, 24-pin (front-plug, rear-mount), Type-C connector. GSCONN part GSC-TYP-0151.

Request a Quote → Download Datasheet
10,000 CyclesRated mating life
24 PinContact count

Technical Specifications

SeriesTYPE-C JACKES
TypeUniversal / 24P
Mating cycles10,000 cycles
Insertion / Removal force5–20 N

Key Features

  • 9.85×9.87×3.16 mm
  • universal type
  • 24-pin (front-plug
  • rear-mount)
  • Type-C connector

Applications

  • Consumer electronics
  • Docking stations and USB hubs
  • Charging and power delivery devices
  • Industrial HMI and control panels
Drawing & Dimensions
TYPE-C socket TYPE-C female connector TYPE-C interface – GSC-TYP-0151 drawing

GSC-TYP-0151 is a type C 24-contact connector, 9.85×9.87×3.16 mm, universal type, 24-pin (front-plug, rear-mount), Type-C connector.

Series TYPE-C JACKES
Type Universal / 24P
Mating cycles 10,000 cycles
Insertion / Removal force 5–20 N

Downloads

Technical DrawingPDF · 113 KB
