TYPE-C socket TYPE-C female connector TYPE-C interface – GSC-TYP-0152
Type C24 Pin
GSC-TYP-0152 is a type C 24-contact connector, 9.7×9.95×3.42 mm, universal type, 24-pin (front-insert, rear-mount) Type-C connector. GSCONN part GSC-TYP-0152.
10,000 CyclesRated mating life
24 PinContact count
Technical Specifications
| Series | TYPE-C JACKES |
| Type | Universal / 24P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 5–20 N |
Key Features
- 9.7×9.95×3.42 mm
- universal type
- 24-pin (front-insert
- rear-mount) Type-C connector
Applications
- Consumer electronics
- Docking stations and USB hubs
- Charging and power delivery devices
- Industrial HMI and control panels
Drawing & Dimensions
GSC-TYP-0152 is a type C 24-contact connector, 9.7×9.95×3.42 mm, universal type, 24-pin (front-insert, rear-mount) Type-C connector.
| Series | TYPE-C JACKES |
|---|---|
| Type | Universal / 24P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 5–20 N |
