TYPE-C socket TYPE-C female connector TYPE-C interface – GSC-TYP-0154
Type C24 Pin
GSC-TYP-0154 is a type C 24-contact connector, 9.2×9.95×3.42 mm, 1.42 mm thick board, 24 pins (front-insertion, rear-mount type), Type-C connector. GSCONN part GSC-TYP-0154.
10,000 CyclesRated mating life
24 PinContact count
Technical Specifications
| Series | TYPE-C JACKES |
| Type | 1.42mm thick board / 24P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 5–20 N |
Key Features
- 9.2×9.95×3.42 mm
- 1.42 mm thick board
- 24 pins (front‑insertion
- rear‑mount type)
- Type‑C connector
Applications
- Consumer electronics
- Docking stations and USB hubs
- Charging and power delivery devices
- Industrial HMI and control panels
Drawing & Dimensions
GSC-TYP-0154 is a type C 24-contact connector, 9.2×9.95×3.42 mm, 1.42 mm thick board, 24 pins (front-insertion, rear-mount type), Type-C connector.
| Series | TYPE-C JACKES |
|---|---|
| Type | 1.42mm thick board / 24P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 5–20 N |
