GSC-TYP-0180 is a type C 24-contact connector, 9.47×4.06×8.64 mm, horizontal, waterproof to IPX7, 24-pin (surface-mount), Type-C connector. GSCONN part GSC-TYP-0180.

Request a Quote → Download Datasheet
WaterproofRated waterproof construction
Surface MountSMT termination
10,000 CyclesRated mating life

Technical Specifications

SeriesTYPE-C JACKES
TypeWaterproof / 24P
Mating cycles10,000 cycles
Insertion / Removal force6–20 N

Key Features

  • 9.47×4.06×8.64 mm
  • horizontal
  • waterproof to IPX7
  • 24-pin (surface-mount)
  • Type-C connector

Applications

  • Consumer electronics
  • Docking stations and USB hubs
  • Charging and power delivery devices
  • Industrial HMI and control panels
Drawing & Dimensions
TYPE-C socket TYPE-C female connector TYPE-C interface – GSC-TYP-0180 drawing

GSC-TYP-0180 is a type C 24-contact connector, 9.47×4.06×8.64 mm, horizontal, waterproof to IPX7, 24-pin (surface-mount), Type-C connector.

Series TYPE-C JACKES
Type Waterproof / 24P
Mating cycles 10,000 cycles
Insertion / Removal force 6–20 N

Downloads

Technical DrawingPDF · 212 KB
