TYPE-C socket TYPE-C female connector TYPE-C interface – GSC-TYP-0183
Type C6 PinSMTRight AngleWaterproof
GSC-TYP-0183 is a type C 6-contact connector, 10×4.66×7.85 mm, horizontal, waterproof to IPX7, 6P (surface-mount type), Type-C connector. GSCONN part GSC-TYP-0183.
WaterproofRated waterproof construction
Surface MountSMT termination
10,000 CyclesRated mating life
Technical Specifications
| Series | TYPE-C JACKES |
| Type | Waterproof / 6P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 5–20 N |
Key Features
- 10×4.66×7.85 mm
- horizontal
- waterproof to IPX7
- 6P (surface-mount type)
- Type-C connector
Applications
- Consumer electronics
- Docking stations and USB hubs
- Charging and power delivery devices
- Industrial HMI and control panels
Drawing & Dimensions
GSC-TYP-0183 is a type C 6-contact connector, 10×4.66×7.85 mm, horizontal, waterproof to IPX7, 6P (surface-mount type), Type-C connector.
| Series | TYPE-C JACKES |
|---|---|
| Type | Waterproof / 6P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 5–20 N |
