TYPE-C socket TYPE-C female connector TYPE-C interface – GSC-TYP-0191

TYPE-C socket TYPE-C female connector TYPE-C interface – GSC-TYP-0191

Type C16 PinThrough-HoleVertical
Tags:
#16 Pin#DIP#PCB#Receptacle#USB Connector#USB Type-C#Vertical
Share:LinkedInFacebookXWhatsAppEmail

GSC-TYP-0191 is a type C 16-contact connector, 8.34×2.56×6.5 mm, vertical, 16-pin (board-mounted plug-in type), Type-C connector. GSCONN part GSC-TYP-0191.

Request a Quote → Download Datasheet
Through-HolePCB solder termination
10,000 CyclesRated mating life
16 PinContact count

Technical Specifications

SeriesTYPE-C JACKES
TypeVertical plug-in / 16P
Mating cycles10,000 cycles
Insertion / Removal force3.57 kgf Max

Key Features

  • 8.34×2.56×6.5 mm
  • vertical
  • 16-pin (board-mounted plug-in type)
  • Type-C connector

Applications

  • Consumer electronics
  • Docking stations and USB hubs
  • Charging and power delivery devices
  • Industrial HMI and control panels
Drawing & Dimensions
TYPE-C socket TYPE-C female connector TYPE-C interface – GSC-TYP-0191 drawing

GSC-TYP-0191 is a type C 16-contact connector, 8.34×2.56×6.5 mm, vertical, 16-pin (board-mounted plug-in type), Type-C connector.

Series TYPE-C JACKES
Type Vertical plug-in / 16P
Mating cycles 10,000 cycles
Insertion / Removal force 3.57 kgf Max

Downloads

Technical DrawingPDF · 57 KB
