TYPE-C socket TYPE-C female connector TYPE-C interface – GSC-TYP-0196
Type C6 PinSMTVertical
GSC-TYP-0196 is a type C 6-contact connector, 8.85×3.06×10 mm, vertical, 6P (surface-mount type), Type-C connector. GSCONN part GSC-TYP-0196.
Surface MountSMT termination
6 PinContact count
Technical Specifications
| Series | TYPE-C JACKES |
| Type | Vertical SMD / 6P |
| Insertion / Removal life | 5,000 cycles |
| Insertion / Removal force | 5–20 N |
Key Features
- 8.85×3.06×10 mm
- vertical
- 6P (surface-mount type)
- Type-C connector
- Insertion / Removal life 5,000 cycles
Applications
- Consumer electronics
- Docking stations and USB hubs
- Charging and power delivery devices
- Industrial HMI and control panels
Drawing & Dimensions
GSC-TYP-0196 is a type C 6-contact connector, 8.85×3.06×10 mm, vertical, 6P (surface-mount type), Type-C connector.
| Series | TYPE-C JACKES |
|---|---|
| Type | Vertical SMD / 6P |
| Insertion / Removal life | 5,000 cycles |
| Insertion / Removal force | 5–20 N |
