TYPE-C socket TYPE-C female connector TYPE-C interface – GSC-TYP-0197
Type C6 PinThrough-HoleVertical
GSC-TYP-0197 is a type C 6-contact connector, 8.95×3.08×10 mm, vertical, 6P (board-mounted plug-in type), Type-C connector. GSCONN part GSC-TYP-0197.
Through-HolePCB solder termination
5,000 CyclesRated mating life
6 PinContact count
Technical Specifications
| Series | TYPE-C JACKES |
| Type | Vertical plug-in / 6P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 5–20 N |
Key Features
- 8.95×3.08×10 mm
- vertical
- 6P (board-mounted plug-in type)
- Type-C connector
Applications
- Consumer electronics
- Docking stations and USB hubs
- Charging and power delivery devices
- Industrial HMI and control panels
Drawing & Dimensions
GSC-TYP-0197 is a type C 6-contact connector, 8.95×3.08×10 mm, vertical, 6P (board-mounted plug-in type), Type-C connector.
| Series | TYPE-C JACKES |
|---|---|
| Type | Vertical plug-in / 6P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 5–20 N |
