TYPE-C socket TYPE-C female connector TYPE-C interface – GSC-TYP-0198

TYPE-C socket TYPE-C female connector TYPE-C interface – GSC-TYP-0198

Type C14 PinThrough-Hole
Tags:
#14 Pin#DIP#PCB#Receptacle#USB Connector#USB Type-C
Share:LinkedInFacebookXWhatsAppEmail

GSC-TYP-0198 is a type C 14-contact connector, terminal H = 1.3 & 1.7 & 2.0 mm, 14P (board-mounted plug-in type), Type-C connector. GSCONN part GSC-TYP-0198.

Request a Quote → Download Datasheet
Through-HolePCB solder termination
10,000 CyclesRated mating life
14 PinContact count

Technical Specifications

SeriesTYPE-C JACKES
TypeH=1.3&1.7&2.0/14P
Mating cycles10,000 cycles
Insertion / Removal force5–20 N

Key Features

  • Terminal H = 1.3 & 1.7 & 2.0 mm
  • 14P (board-mounted plug-in type)
  • Type-C connector

Applications

  • Consumer electronics
  • Docking stations and USB hubs
  • Charging and power delivery devices
  • Industrial HMI and control panels
Drawing & Dimensions
TYPE-C socket TYPE-C female connector TYPE-C interface – GSC-TYP-0198 drawing

GSC-TYP-0198 is a type C 14-contact connector, terminal H = 1.3 & 1.7 & 2.0 mm, 14P (board-mounted plug-in type), Type-C connector.

Series TYPE-C JACKES
Type H=1.3&1.7&2.0/14P
Mating cycles 10,000 cycles
Insertion / Removal force 5–20 N

Downloads

Technical DrawingPDF · 60 KB
