TYPE-C socket TYPE-C female connector TYPE-C interface – GSC-TYP-0203
Type C6 PinSMT
GSC-TYP-0203 is a type C 6-contact connector, 6P H=4.5&5.0&5.5&6.0&6.5&6.8&7.8 (Surface-Mount Type) TYPE-C Connector. GSCONN part GSC-TYP-0203.
Surface MountSMT termination
10,000 CyclesRated mating life
6 PinContact count
Technical Specifications
| Series | TYPE-C JACKES |
| Type | Multiple heights / 6P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 5–2.0 kgf |
Key Features
- 6P H=4.5&5.0&5.5&6.0&6.5&6.8&7.8 (Surface-Mount Type) TYPE-C Connector
Applications
- Consumer electronics
- Docking stations and USB hubs
- Charging and power delivery devices
- Industrial HMI and control panels
Drawing & Dimensions
GSC-TYP-0203 is a type C 6-contact connector, 6P H=4.5&5.0&5.5&6.0&6.5&6.8&7.8 (Surface-Mount Type) TYPE-C Connector.
| Series | TYPE-C JACKES |
|---|---|
| Type | Multiple heights / 6P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 5–2.0 kgf |
