TYPE-C socket防水 TYPE-C female connector防水 TYPE-C interface TYPE-C-31-E-09 – GSC-TYP-0175
Type C6 PinSMTWaterproof
GSC-TYP-0175 is a type C 6-contact connector, 10.54×4.76×8.2 mm, flush-mount type, waterproof to IPX7, 6P (surface-mount), Type-C connector. GSCONN part GSC-TYP-0175.
WaterproofRated waterproof construction
Surface MountSMT termination
10,000 CyclesRated mating life
Technical Specifications
| Series | TYPE-C JACKES |
| Type | Recessed Plate Waterproof Type / 6P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- 10.54×4.76×8.2 mm
- flush-mount type
- waterproof to IPX7
- 6P (surface-mount)
- Type-C connector
Applications
- Consumer electronics
- Docking stations and USB hubs
- Charging and power delivery devices
- Industrial HMI and control panels
Drawing & Dimensions
GSC-TYP-0175 is a type C 6-contact connector, 10.54×4.76×8.2 mm, flush-mount type, waterproof to IPX7, 6P (surface-mount), Type-C connector.
| Series | TYPE-C JACKES |
|---|---|
| Type | Recessed Plate Waterproof Type / 6P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 3–20 N |
