TYPE-C socket TYPE-C female connector vertical TYPE-C interface – GSC-TYP-0133

TYPE-C socket TYPE-C female connector vertical TYPE-C interface – GSC-TYP-0133

Type C24 PinThrough-HoleVertical
Tags:
#24 Pin#DIP#PCB#Receptacle#USB Connector#USB Type-C#Vertical
Share:LinkedInFacebookXWhatsAppEmail

GSC-TYP-0133 is a type C 24-contact connector, vertical 24P, multiple height options (board-mounted plug-in type), Type-C interface. GSCONN part GSC-TYP-0133.

Request a Quote → Download Datasheet
Through-HolePCB solder termination
24 PinContact count

Technical Specifications

SeriesTYPE-C JACKETS
TypeVertical Plug-in / 24P
Mating cycles10,000
Insertion / Removal force5–20 N

Key Features

  • Vertical 24P
  • multiple height options (board-mounted plug-in type)
  • Type-C interface

Applications

  • Consumer electronics
  • Docking stations and USB hubs
  • Charging and power delivery devices
  • Industrial HMI and control panels
Drawing & Dimensions
TYPE-C socket TYPE-C female connector vertical TYPE-C interface – GSC-TYP-0133 drawing

GSC-TYP-0133 is a type C 24-contact connector, vertical 24P, multiple height options (board-mounted plug-in type), Type-C interface.

Series TYPE-C JACKETS
Type Vertical Plug-in / 24P
Mating cycles 10,000
Insertion / Removal force 5–20 N

Downloads

Technical DrawingPDF · 91 KB
