TYPE-C socket TYPE-C female connector vertical TYPE-C interface – GSC-TYP-0190

TYPE-C socket TYPE-C female connector vertical TYPE-C interface – GSC-TYP-0190

Type C16 PinThrough-HoleVertical
Tags:
#16 Pin#DIP#PCB#Receptacle#USB Connector#USB Type-C#Vertical
Share:LinkedInFacebookXWhatsAppEmail

GSC-TYP-0190 is a type C 16-contact connector, 12×5×(8.8–9.3) mm, vertical, 16P (board-mounted plug-in type), Type-C connector. GSCONN part GSC-TYP-0190.

Request a Quote → Download Datasheet
Through-HolePCB solder termination
10,000 CyclesRated mating life
16 PinContact count

Technical Specifications

SeriesTYPE-C JACKES
TypeVertical plug-in / 16P
Mating cycles10,000 cycles
Insertion / Removal force5–20 N

Key Features

  • 12×5×(8.8–9.3) mm
  • vertical
  • 16P (board-mounted plug-in type)
  • Type-C connector

Applications

  • Consumer electronics
  • Docking stations and USB hubs
  • Charging and power delivery devices
  • Industrial HMI and control panels
Drawing & Dimensions
TYPE-C socket TYPE-C female connector vertical TYPE-C interface – GSC-TYP-0190 drawing

GSC-TYP-0190 is a type C 16-contact connector, 12×5×(8.8–9.3) mm, vertical, 16P (board-mounted plug-in type), Type-C connector.

Series TYPE-C JACKES
Type Vertical plug-in / 16P
Mating cycles 10,000 cycles
Insertion / Removal force 5–20 N

Downloads

Technical DrawingPDF · 93 KB
