TYPE-C socket vertical TYPE-C female connector raised TYPE-C interface – GSC-TYP-0185

TYPE-C socket vertical TYPE-C female connector raised TYPE-C interface – GSC-TYP-0185

Type C16 PinSMTVertical
Tags:
#16 Pin#PCB#Receptacle#SMT#USB Connector#USB Type-C#Vertical
Share:LinkedInFacebookXWhatsAppEmail

GSC-TYP-0185 is a type C 16-contact connector, h=8.8/9.3/10/10.5mm and other heights; vertical 16P (surface-mount) TYPE-C connector. GSCONN part GSC-TYP-0185.

Request a Quote → Download Datasheet
Surface MountSMT termination
10,000 CyclesRated mating life
16 PinContact count

Technical Specifications

SeriesTYPE-C JACKES
TypeVertical SMD / 16P
Mating cycles10,000 cycles
Insertion / Removal force0.5–2.0 kgf

Key Features

  • H=8.8/9.3/10/10.5mm and other heights
  • vertical 16P (surface-mount) TYPE‑C connector

Applications

  • Consumer electronics
  • Docking stations and USB hubs
  • Charging and power delivery devices
  • Industrial HMI and control panels
Drawing & Dimensions
TYPE-C socket vertical TYPE-C female connector raised TYPE-C interface – GSC-TYP-0185 drawing

GSC-TYP-0185 is a type C 16-contact connector, h=8.8/9.3/10/10.5mm and other heights; vertical 16P (surface-mount) TYPE-C connector.

Series TYPE-C JACKES
Type Vertical SMD / 16P
Mating cycles 10,000 cycles
Insertion / Removal force 0.5–2.0 kgf
