TYPE-C socket vertical TYPE-C female connector raised TYPE-C interface – GSC-TYP-0186
Type C24 PinSMTVertical
GSC-TYP-0186 is a type C 24-contact connector, 11×7×15 mm, vertical, 24-pin (surface-mount), Type-C connector. GSCONN part GSC-TYP-0186.
Surface MountSMT termination
10,000 CyclesRated mating life
24 PinContact count
Technical Specifications
| Series | TYPE-C JACKES |
| Type | Vertical SMD / 24P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 5–20 N |
Key Features
- 11×7×15 mm
- vertical
- 24-pin (surface-mount)
- Type-C connector
Applications
- Consumer electronics
- Docking stations and USB hubs
- Charging and power delivery devices
- Industrial HMI and control panels
Drawing & Dimensions
GSC-TYP-0186 is a type C 24-contact connector, 11×7×15 mm, vertical, 24-pin (surface-mount), Type-C connector.
| Series | TYPE-C JACKES |
|---|---|
| Type | Vertical SMD / 24P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 5–20 N |
