GSC-TYP-0171 is a type C 16-contact connector, h=13/13.7/15/17.5/18.5mm, various heights; vertical 16P (board-mounted plug-in) TYPE-C socket. GSCONN part GSC-TYP-0171.

Request a Quote → Download Datasheet
Through-HolePCB solder termination
10,000 CyclesRated mating life
16 PinContact count

Technical Specifications

SeriesTYPE-C JACKES
TypeVertical Plug / 16P
Mating cycles10,000 cycles
Insertion / Removal force0.5–2.0 kgf

Key Features

  • H=13/13.7/15/17.5/18.5mm
  • various heights
  • vertical 16P (board-mounted plug-in) TYPE‑C socket

Applications

  • Consumer electronics
  • Docking stations and USB hubs
  • Charging and power delivery devices
  • Industrial HMI and control panels
Drawing & Dimensions
TYPE-C Socket Vertical TYPE-C Female Connector TYPE-C Interface – GSC-TYP-0171 drawing

GSC-TYP-0171 is a type C 16-contact connector, h=13/13.7/15/17.5/18.5mm, various heights; vertical 16P (board-mounted plug-in) TYPE-C socket.

Series TYPE-C JACKES
Type Vertical Plug / 16P
Mating cycles 10,000 cycles
Insertion / Removal force 0.5–2.0 kgf

Downloads

Technical DrawingPDF · 82 KB
