TYPE-C Socket Waterproof TYPE-C Female Connector Horizontal TYPE-C Interface – GSC-TYP-0182

TYPE-C Socket Waterproof TYPE-C Female Connector Horizontal TYPE-C Interface – GSC-TYP-0182

Type C16 PinSMTRight AngleWaterproof
Tags:
#16 Pin#PCB#Receptacle#Right Angle#SMT#USB Connector#USB Type-C#Waterproof
Share:LinkedInFacebookXWhatsAppEmail

GSC-TYP-0182 is a type C 16-contact connector, 10×4.56×7.85 mm, horizontal, waterproof, 16-pin (surface-mount), Type-C connector. GSCONN part GSC-TYP-0182.

Request a Quote → Download Datasheet
WaterproofRated waterproof construction
Surface MountSMT termination
10,000 CyclesRated mating life

Technical Specifications

SeriesTYPE-C JACKES
TypeWaterproof / 16P
Mating cycles10,000 cycles
Insertion / Removal force6–20 N

Key Features

  • 10×4.56×7.85 mm
  • horizontal
  • waterproof
  • 16-pin (surface-mount)
  • Type-C connector

Applications

  • Consumer electronics
  • Docking stations and USB hubs
  • Charging and power delivery devices
  • Industrial HMI and control panels
Drawing & Dimensions
TYPE-C Socket Waterproof TYPE-C Female Connector Horizontal TYPE-C Interface – GSC-TYP-0182 drawing

GSC-TYP-0182 is a type C 16-contact connector, 10×4.56×7.85 mm, horizontal, waterproof, 16-pin (surface-mount), Type-C connector.

Series TYPE-C JACKES
Type Waterproof / 16P
Mating cycles 10,000 cycles
Insertion / Removal force 6–20 N

Downloads

Technical DrawingPDF · 85 KB
