GSC-TYP-0153 is a type C 16-contact connector, 9.85×4.06×8.65 mm, horizontal type with mounting holes, IPX7, 16P (surface-mount), TYPE-C connector. GSCONN part GSC-TYP-0153.

Request a Quote → Download Datasheet
WaterproofRated waterproof construction
Surface MountSMT termination
10,000 CyclesRated mating life

Technical Specifications

SeriesTYPE-C JACKES
TypeVertical Waterproof Type / 16P
Mating cycles10,000 cycles
Insertion / Removal force3–20 N

Key Features

  • 9.85×4.06×8.65 mm
  • horizontal type with mounting holes
  • 16P (surface-mount)
  • TYPE‑C connector

Applications

  • Consumer electronics
  • Docking stations and USB hubs
  • Charging and power delivery devices
  • Industrial HMI and control panels
Drawing & Dimensions
TYPE-C socket waterproof TYPE-C female connector horizontally mounted with mounting holes TYPE-C interface – GSC-TYP-0153 drawing

GSC-TYP-0153 is a type C 16-contact connector, 9.85×4.06×8.65 mm, horizontal type with mounting holes, IPX7, 16P (surface-mount), TYPE-C connector.

Series TYPE-C JACKES
Type Vertical Waterproof Type / 16P
Mating cycles 10,000 cycles
Insertion / Removal force 3–20 N
