GSC-TYP-0169 is a type C 16-contact connector, 9.68×3.9×5.75 mm, vertical, waterproof to IPX6, 16-pin (surface-mount type), Type-C connector. GSCONN part GSC-TYP-0169.

Request a Quote → Download Datasheet
WaterproofRated waterproof construction
Surface MountSMT termination
10,000 CyclesRated mating life

Technical Specifications

SeriesTYPE-C JACKES
TypeVertical Waterproof Type / 16P
Mating cycles10,000 cycles
Insertion / Removal force5–20 N

Key Features

  • 9.68×3.9×5.75 mm
  • vertical
  • waterproof to IPX6
  • 16-pin (surface-mount type)
  • Type-C connector

Applications

  • Consumer electronics
  • Docking stations and USB hubs
  • Charging and power delivery devices
  • Industrial HMI and control panels
Drawing & Dimensions
TYPE-C socket waterproof TYPE-C female connector waterproof TYPE-C interface – GSC-TYP-0169 drawing

GSC-TYP-0169 is a type C 16-contact connector, 9.68×3.9×5.75 mm, vertical, waterproof to IPX6, 16-pin (surface-mount type), Type-C connector.

Series TYPE-C JACKES
Type Vertical Waterproof Type / 16P
Mating cycles 10,000 cycles
Insertion / Removal force 5–20 N

Downloads

Technical DrawingPDF · 77 KB
