TYPE-C socket waterproof TYPE-C female connector waterproof TYPE-C interface – GSC-TYP-0172
Type C24 PinSMTWaterproof
GSC-TYP-0172 is a type C 24-contact connector, 9.8×4.02×9.65 mm, flush-mount, waterproof to IPX7, 24-pin (surface-mount), Type-C connector. GSCONN part GSC-TYP-0172.
WaterproofRated waterproof construction
Surface MountSMT termination
10,000 CyclesRated mating life
Technical Specifications
| Series | TYPE-C JACKES |
| Type | Recessed waterproof type / 24P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 6–20 N |
Key Features
- 9.8×4.02×9.65 mm
- flush‑mount
- waterproof to IPX7
- 24‑pin (surface‑mount)
- Type‑C connector
Applications
- Consumer electronics
- Docking stations and USB hubs
- Charging and power delivery devices
- Industrial HMI and control panels
Drawing & Dimensions
GSC-TYP-0172 is a type C 24-contact connector, 9.8×4.02×9.65 mm, flush-mount, waterproof to IPX7, 24-pin (surface-mount), Type-C connector.
| Series | TYPE-C JACKES |
|---|---|
| Type | Recessed waterproof type / 24P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 6–20 N |
