TYPE-C socket waterproof TYPE-C female connector waterproof TYPE-C interface – GSC-TYP-0173

TYPE-C socket waterproof TYPE-C female connector waterproof TYPE-C interface – GSC-TYP-0173

Type C6 PinVerticalWaterproof
Tags:
#6 Pin#Receptacle#USB Connector#USB Type-C#Vertical#Waterproof
Share:LinkedInFacebookXWhatsAppEmail

GSC-TYP-0173 is a type C 6-contact connector, 11.4×5.6×6.8 mm, vertical, waterproof to IPX7, 6P (board-mount type), Type-C connector. GSCONN part GSC-TYP-0173.

Request a Quote → Download Datasheet
WaterproofRated waterproof construction
10,000 CyclesRated mating life
6 PinContact count

Technical Specifications

SeriesTYPE-C JACKES
TypeVertical Waterproof / 6P
Mating cycles10,000 cycles
Insertion / Removal force5–20 N

Key Features

  • 11.4×5.6×6.8 mm
  • vertical
  • waterproof to IPX7
  • 6P (board-mount type)
  • Type-C connector

Applications

  • Consumer electronics
  • Docking stations and USB hubs
  • Charging and power delivery devices
  • Industrial HMI and control panels
Drawing & Dimensions
TYPE-C socket waterproof TYPE-C female connector waterproof TYPE-C interface – GSC-TYP-0173 drawing

GSC-TYP-0173 is a type C 6-contact connector, 11.4×5.6×6.8 mm, vertical, waterproof to IPX7, 6P (board-mount type), Type-C connector.

Series TYPE-C JACKES
Type Vertical Waterproof / 6P
Mating cycles 10,000 cycles
Insertion / Removal force 5–20 N

Downloads

Technical DrawingPDF · 62 KB
