USB Socket Flat-Port USB Female Connector Flat-Port USB Interface – GSC-USA-0057
USB4 Pin
GSC-USA-0057 is a USB 4-contact connector, 13.1×5.75×13.8 mm, flush-mount, flat-face, 4-pole (board-mount type) USB socket. GSCONN part GSC-USA-0057.
10,000 CyclesRated mating life
4 PinContact count
Technical Specifications
| Series | USB JACK |
| Type | Flush-mounted / 4P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 3.57 kgf MAX |
Key Features
- 13.1×5.75×13.8 mm
- flush-mount
- flat‑face
- 4‑pole (board‑mount type) USB socket
Applications
- Consumer electronics
- USB peripherals and hubs
- Charging devices
- Industrial control equipment
Drawing & Dimensions
GSC-USA-0057 is a USB 4-contact connector, 13.1×5.75×13.8 mm, flush-mount, flat-face, 4-pole (board-mount type) USB socket.
| Series | USB JACK |
|---|---|
| Type | Flush-mounted / 4P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 3.57 kgf MAX |
