USB Socket Flat-Port USB Female Connector SMD USB Interface – GSC-USA-0031
USB4 PinSMTRight Angle
GSC-USA-0031 is a USB 4-contact connector, 13.8×7.1×12.5 mm horizontal SMD 4P flat-foot (surface-mount) USB socket. GSCONN part GSC-USA-0031.
Surface MountSMT termination
3,000 CyclesRated mating life
4 PinContact count
Technical Specifications
| Series | USB JACK |
| Type | Surface-mount / 4P |
| Mating cycles | 3,000 cycles |
| Insertion / Removal force | 3.57 kgf MAX |
Key Features
- 13.8×7.1×12.5 mm horizontal SMD 4P flat‑foot (surface‑mount) USB socket
Applications
- Consumer electronics
- USB peripherals and hubs
- Charging devices
- Industrial control equipment
Drawing & Dimensions
GSC-USA-0031 is a USB 4-contact connector, 13.8×7.1×12.5 mm horizontal SMD 4P flat-foot (surface-mount) USB socket.
| Series | USB JACK |
|---|---|
| Type | Surface-mount / 4P |
| Mating cycles | 3,000 cycles |
| Insertion / Removal force | 3.57 kgf MAX |
