USB Socket Horizontal USB Female Connector USB 3.0 Interface – GSC-USA-0028
USB9 PinSMTRight Angle
GSC-USA-0028 is a USB 9-contact connector, 13.1×14.45×5.72 mm, horizontal, 9P (surface-mount), USB socket. GSCONN part GSC-USA-0028.
Surface MountSMT termination
1,200 CyclesRated mating life
9 PinContact count
Technical Specifications
| Series | USB JACK |
| Type | Horizontal SMD / 9P |
| Mating cycles | 1,200 cycles |
| Insertion / Removal force | 3.57 kgf Max |
Key Features
- 13.1×14.45×5.72 mm
- horizontal
- 9P (surface-mount)
- USB socket
Applications
- Consumer electronics
- USB peripherals and hubs
- Charging devices
- Industrial control equipment
Drawing & Dimensions
GSC-USA-0028 is a USB 9-contact connector, 13.1×14.45×5.72 mm, horizontal, 9P (surface-mount), USB socket.
| Series | USB JACK |
|---|---|
| Type | Horizontal SMD / 9P |
| Mating cycles | 1,200 cycles |
| Insertion / Removal force | 3.57 kgf Max |
