USB Socket Horizontal USB Female Connector USB Interface – GSC-USA-0049
USB4 PinSMTRight Angle
GSC-USA-0049 is a USB 4-contact connector, 14.6×6.9×10 mm, horizontal, 4P, available in black or white (surface-mount type), USB socket. GSCONN part GSC-USA-0049.
Surface MountSMT termination
10,000 CyclesRated mating life
4 PinContact count
Technical Specifications
| Series | USB JACK |
| Type | Black/White/ 4P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 3.57 kgf MAX |
Key Features
- 14.6×6.9×10 mm
- horizontal
- available in black or white (surface-mount type)
- USB socket
Applications
- Consumer electronics
- USB peripherals and hubs
- Charging devices
- Industrial control equipment
Drawing & Dimensions
GSC-USA-0049 is a USB 4-contact connector, 14.6×6.9×10 mm, horizontal, 4P, available in black or white (surface-mount type), USB socket.
| Series | USB JACK |
|---|---|
| Type | Black/White/ 4P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 3.57 kgf MAX |
