USB socket MICRO USB female connector SMD USB interface – GSC-USA-0104

USB socket MICRO USB female connector SMD USB interface – GSC-USA-0104

USB4 PinSMTRight Angle
Tags:
#4 Pin#PCB#Receptacle#Right Angle#SMT#USB Connector#USB Type-A
Share:LinkedInFacebookXWhatsAppEmail

GSC-USA-0104 is a USB 4-contact connector, 7.59×5.6×3.0 mm, horizontal, 4P fixed leads (surface-mount type), Micro USB connector. GSCONN part GSC-USA-0104.

Request a Quote → Download Datasheet
Surface MountSMT termination
10,000 CyclesRated mating life
4 PinContact count

Technical Specifications

SeriesMICRO USB JACK
Type4P fixed foot
Mating cycles10,000 cycles
Insertion / Removal force3–20 N

Key Features

  • 7.59×5.6×3.0 mm
  • horizontal
  • 4P fixed leads (surface-mount type)
  • Micro USB connector

Applications

  • Consumer electronics
  • USB peripherals and hubs
  • Charging devices
  • Industrial control equipment
Drawing & Dimensions
USB socket MICRO USB female connector SMD USB interface – GSC-USA-0104 drawing

GSC-USA-0104 is a USB 4-contact connector, 7.59×5.6×3.0 mm, horizontal, 4P fixed leads (surface-mount type), Micro USB connector.

Series MICRO USB JACK
Type 4P fixed foot
Mating cycles 10,000 cycles
Insertion / Removal force 3–20 N

Downloads

Technical DrawingPDF · 44 KB
