USB socket MICRO USB female connector with curled edge USB interface – GSC-USA-0102
USBSMTRight Angle
GSC-USA-0102 is a USB connector, 7.5×5.8×2.4 mm, horizontal type, 5.6 mm pitch (surface-mount), Micro USB connector. GSCONN part GSC-USA-0102.
Surface MountSMT termination
10,000 CyclesRated mating life
Technical Specifications
| Series | MICRO USB JACK |
| Type | Pitch 5.6 mm |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 3–20 N |
Key Features
- 7.5×5.8×2.4 mm
- horizontal type
- 5.6 mm pitch (surface-mount)
- Micro USB connector
Applications
- Consumer electronics
- USB peripherals and hubs
- Charging devices
- Industrial control equipment
Drawing & Dimensions
GSC-USA-0102 is a USB connector, 7.5×5.8×2.4 mm, horizontal type, 5.6 mm pitch (surface-mount), Micro USB connector.
| Series | MICRO USB JACK |
|---|---|
| Type | Pitch 5.6 mm |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 3–20 N |
