USB Socket Reversible USB Female Connector Side-Entry USB Interface – GSC-USA-0043
USB8 PinRight Angle
GSC-USA-0043 is a USB 8-contact connector, 12.9×6.4×12 mm, horizontal orientation, reversible insertion, 8P (board-mounted type) USB socket. GSCONN part GSC-USA-0043.
10,000 CyclesRated mating life
8 PinContact count
Technical Specifications
| Series | USB JACK |
| Type | Reversible plug / 8P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 8–20 N |
Key Features
- 12.9×6.4×12 mm
- horizontal orientation
- reversible insertion
- 8P (board-mounted type) USB socket
Applications
- Consumer electronics
- USB peripherals and hubs
- Charging devices
- Industrial control equipment
Drawing & Dimensions
GSC-USA-0043 is a USB 8-contact connector, 12.9×6.4×12 mm, horizontal orientation, reversible insertion, 8P (board-mounted type) USB socket.
| Series | USB JACK |
|---|---|
| Type | Reversible plug / 8P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 8–20 N |
