USB Socket SMD USB Female Connector USB 2.0 Interface – GSC-USA-0048
USB4 PinSMTRight Angle
GSC-USA-0048 is a USB 4-contact connector, 13.7×5.75×13.15 mm, horizontal, 4P, flat-bottom (surface-mount), USB socket. GSCONN part GSC-USA-0048.
Surface MountSMT termination
5,000 CyclesRated mating life
4 PinContact count
Technical Specifications
| Series | USB JACK |
| Type | Horizontal SMD / 4P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3.57 kgf MAX |
Key Features
- 13.7×5.75×13.15 mm
- horizontal
- flat‑bottom (surface‑mount)
- USB socket
Applications
- Consumer electronics
- USB peripherals and hubs
- Charging devices
- Industrial control equipment
Drawing & Dimensions
GSC-USA-0048 is a USB 4-contact connector, 13.7×5.75×13.15 mm, horizontal, 4P, flat-bottom (surface-mount), USB socket.
| Series | USB JACK |
|---|---|
| Type | Horizontal SMD / 4P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3.57 kgf MAX |
