USB Socket Socketed USB Female Connector Flange-Type USB Interface – GSC-USA-0059
USB4 PinSMTThrough-Hole
GSC-USA-0059 is a USB 4-contact connector, 13.1×5.7×11.05 mm, surface-mount, 8-pin flat-type USB socket. GSCONN part GSC-USA-0059.
Surface MountSMT termination
3,000 CyclesRated mating life
4 PinContact count
Technical Specifications
| Series | USB JACK |
| Type | SMD, through-hole / 4P |
| Mating cycles | 3,000 cycles |
| Insertion / Removal force | 3.5 kgf MAX |
Key Features
- 13.1×5.7×11.05 mm
- surface-mount
- 8-pin flat‑type USB socket
Applications
- Consumer electronics
- USB peripherals and hubs
- Charging devices
- Industrial control equipment
Drawing & Dimensions
GSC-USA-0059 is a USB 4-contact connector, 13.1×5.7×11.05 mm, surface-mount, 8-pin flat-type USB socket.
| Series | USB JACK |
|---|---|
| Type | SMD, through-hole / 4P |
| Mating cycles | 3,000 cycles |
| Insertion / Removal force | 3.5 kgf MAX |
