USB Socket Socketed USB Female Connector Flange-Type USB Interface – GSC-USA-0060

USB Socket Socketed USB Female Connector Flange-Type USB Interface – GSC-USA-0060

USB8 PinThrough-Hole
Tags:
#8 Pin#DIP#PCB#Receptacle#USB Connector#USB Type-A
Share:LinkedInFacebookXWhatsAppEmail

GSC-USA-0060 is a USB 8-contact connector, 13.1×5.7×11.00 mm, flush-mount type, 8P, flat-face (board-mount plug-in) USB socket. GSCONN part GSC-USA-0060.

Request a Quote → Download Datasheet
Through-HolePCB solder termination
5,000 CyclesRated mating life
8 PinContact count

Technical Specifications

SeriesUSB JACK
TypePanel-mount plug-in / 4P
Mating cycles5,000 cycles
Insertion / Removal force3.5 kgf MAX

Key Features

  • 13.1×5.7×11.00 mm
  • flush-mount type
  • flat‑face (board‑mount plug‑in) USB socket

Applications

  • Consumer electronics
  • USB peripherals and hubs
  • Charging devices
  • Industrial control equipment
Drawing & Dimensions
USB Socket Socketed USB Female Connector Flange-Type USB Interface – GSC-USA-0060 drawing

GSC-USA-0060 is a USB 8-contact connector, 13.1×5.7×11.00 mm, flush-mount type, 8P, flat-face (board-mount plug-in) USB socket.

Series USB JACK
Type Panel-mount plug-in / 4P
Mating cycles 5,000 cycles
Insertion / Removal force 3.5 kgf MAX

Downloads

Technical DrawingPDF · 53 KB
