USB Socket Surface-Mount USB Female Connector USB 2.0 Interface – GSC-USA-0050
USB4 PinThrough-HoleRight Angle
GSC-USA-0050 is a USB 4-contact connector, 10×5.7×13.1 mm, horizontal, 4P, flat-bottom (board-mount type) USB socket. GSCONN part GSC-USA-0050.
Through-HolePCB solder termination
5,000 CyclesRated mating life
4 PinContact count
Technical Specifications
| Series | USB JACK |
| Type | Horizontal plug-in / 4P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3.75 kgf MAX |
Key Features
- 10×5.7×13.1 mm
- horizontal
- flat‑bottom (board‑mount type) USB socket
Applications
- Consumer electronics
- USB peripherals and hubs
- Charging devices
- Industrial control equipment
Drawing & Dimensions
GSC-USA-0050 is a USB 4-contact connector, 10×5.7×13.1 mm, horizontal, 4P, flat-bottom (board-mount type) USB socket.
| Series | USB JACK |
|---|---|
| Type | Horizontal plug-in / 4P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3.75 kgf MAX |
