USB socket USB 2.0 female connector vertical USB port – GSC-USA-0056
USB4 PinThrough-HoleVertical
GSC-USA-0056 is a USB 4-contact connector, 13.1×5.75×10 mm Vertical 4P (Board-Mounted Plug-In Type) USB Socket. GSCONN part GSC-USA-0056.
Through-HolePCB solder termination
5,000 CyclesRated mating life
4 PinContact count
Technical Specifications
| Series | USB JACK |
| Type | Vertical plug-in / 4P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3.57 kg MAX |
Key Features
- 13.1×5.75×10 mm Vertical 4P (Board-Mounted Plug-In Type) USB Socket
Applications
- Consumer electronics
- USB peripherals and hubs
- Charging devices
- Industrial control equipment
Drawing & Dimensions
GSC-USA-0056 is a USB 4-contact connector, 13.1×5.75×10 mm Vertical 4P (Board-Mounted Plug-In Type) USB Socket.
| Series | USB JACK |
|---|---|
| Type | Vertical plug-in / 4P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 3.57 kg MAX |
