USB socket USB 3.0 female connector pin-type USB interface – GSC-USA-0034
USB9 PinThrough-HoleRight Angle
GSC-USA-0034 is a USB 9-contact connector, 14×16.5×6.95 mm, horizontal, 9P (board-mounted plug-in type) USB socket. GSCONN part GSC-USA-0034.
Through-HolePCB solder termination
1,500 CyclesRated mating life
9 PinContact count
Technical Specifications
| Series | USB JACK |
| Type | Horizontal plug-in / 9P |
| Mating cycles | 1,500 cycles |
| Insertion / Removal force | 3.57 kgf Max |
Key Features
- 14×16.5×6.95 mm
- horizontal
- 9P (board-mounted plug-in type) USB socket
Applications
- Consumer electronics
- USB peripherals and hubs
- Charging devices
- Industrial control equipment
Drawing & Dimensions
GSC-USA-0034 is a USB 9-contact connector, 14×16.5×6.95 mm, horizontal, 9P (board-mounted plug-in type) USB socket.
| Series | USB JACK |
|---|---|
| Type | Horizontal plug-in / 9P |
| Mating cycles | 1,500 cycles |
| Insertion / Removal force | 3.57 kgf Max |
