USB socket USB Type-B female connector USB Type-B interface – GSC-USA-0070
USB9 PinThrough-HoleRight Angle
GSC-USA-0070 is a USB 9-contact connector, 12×12.9×18.3 mm, horizontal, 9P (board-mounted plug-in type) USB socket. GSCONN part GSC-USA-0070.
Through-HolePCB solder termination
1,500 CyclesRated mating life
9 PinContact count
Technical Specifications
| Series | USB JACK |
| Type | USB Type-B / Horizontal Plug-In |
| Mating cycles | 1,500 cycles |
| Insertion / Removal force | 35 N MAX |
Key Features
- 12×12.9×18.3 mm
- horizontal
- 9P (board-mounted plug-in type) USB socket
Applications
- Consumer electronics
- USB peripherals and hubs
- Charging devices
- Industrial control equipment
Drawing & Dimensions
GSC-USA-0070 is a USB 9-contact connector, 12×12.9×18.3 mm, horizontal, 9P (board-mounted plug-in type) USB socket.
| Series | USB JACK |
|---|---|
| Type | USB Type-B / Horizontal Plug-In |
| Mating cycles | 1,500 cycles |
| Insertion / Removal force | 35 N MAX |
