USB Socket Vertical USB Female Connector Plug-in USB Interface – GSC-USA-0036
USB9 PinThrough-HoleVertical
GSC-USA-0036 is a USB 9-contact connector, 13.1×11.5×5.7 mm, vertical, 9P (board-mounted plug-in type) USB socket. GSCONN part GSC-USA-0036.
Through-HolePCB solder termination
3,000 CyclesRated mating life
9 PinContact count
Technical Specifications
| Series | USB JACK |
| Type | Vertical plug-in / 9P |
| Mating cycles | 3,000 cycles |
| Insertion / Removal force | 3.57 kgf MAX |
Key Features
- 13.1×11.5×5.7 mm
- vertical
- 9P (board-mounted plug-in type) USB socket
Applications
- Consumer electronics
- USB peripherals and hubs
- Charging devices
- Industrial control equipment
Drawing & Dimensions
GSC-USA-0036 is a USB 9-contact connector, 13.1×11.5×5.7 mm, vertical, 9P (board-mounted plug-in type) USB socket.
| Series | USB JACK |
|---|---|
| Type | Vertical plug-in / 9P |
| Mating cycles | 3,000 cycles |
| Insertion / Removal force | 3.57 kgf MAX |
