USB Socket Vertical USB Female Connector Short-Body USB Interface – GSC-USA-0052
USB8 PinThrough-HoleVertical
GSC-USA-0052 is a USB 8-contact connector, 14.3×6.9×10 mm, vertical, 8P, available in black or white (board-mounted plug-in type) USB socket. GSCONN part GSC-USA-0052.
Through-HolePCB solder termination
10,000 CyclesRated mating life
8 PinContact count
Technical Specifications
| Series | USB JACK |
| Type | Short-body plugin / 4P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 3.57 kgf MAX |
Key Features
- 14.3×6.9×10 mm
- vertical
- available in black or white (board-mounted plug-in type) USB socket
Applications
- Consumer electronics
- USB peripherals and hubs
- Charging devices
- Industrial control equipment
Drawing & Dimensions
GSC-USA-0052 is a USB 8-contact connector, 14.3×6.9×10 mm, vertical, 8P, available in black or white (board-mounted plug-in type) USB socket.
| Series | USB JACK |
|---|---|
| Type | Short-body plugin / 4P |
| Mating cycles | 10,000 cycles |
| Insertion / Removal force | 3.57 kgf MAX |
