USB Socket Vertical USB Female Connector USB Interface – GSC-USA-0051

USB Socket Vertical USB Female Connector USB Interface – GSC-USA-0051

USB4 PinThrough-HoleVertical
Tags:
#4 Pin#DIP#PCB#Receptacle#USB Connector#USB Type-A#Vertical
Share:LinkedInFacebookXWhatsAppEmail

GSC-USA-0051 is a USB 4-contact connector, h=13&13.7&15mm Vertical 4P Black & White Optional (Board-Mounted Plug-In Type) USB Socket. GSCONN part GSC-USA-0051.

Request a Quote → Download Datasheet
Through-HolePCB solder termination
10,000 CyclesRated mating life
4 PinContact count

Technical Specifications

SeriesUSB JACK
TypeVertical plug-in / 4P
Mating cycles10,000 cycles
Insertion / Removal force4.0 kgf MAX

Key Features

  • H=13&13.7&15mm Vertical 4P Black & White Optional (Board-Mounted Plug-In Type) USB Socket

Applications

  • Consumer electronics
  • USB peripherals and hubs
  • Charging devices
  • Industrial control equipment
Drawing & Dimensions
USB Socket Vertical USB Female Connector USB Interface – GSC-USA-0051 drawing

GSC-USA-0051 is a USB 4-contact connector, h=13&13.7&15mm Vertical 4P Black & White Optional (Board-Mounted Plug-In Type) USB Socket.

Series USB JACK
Type Vertical plug-in / 4P
Mating cycles 10,000 cycles
Insertion / Removal force 4.0 kgf MAX

Downloads

Technical DrawingPDF · 41 KB
