USB Socket Vertical USB Female Connector Vertical USB Port – GSC-USA-0039
USB4 PinThrough-HoleVertical
GSC-USA-0039 is a USB 4-contact connector, 13.2×6.9×H=13&13.7&15mm Vertical 4P (board-mounted plug-in) USB socket. GSCONN part GSC-USA-0039.
Through-HolePCB solder termination
5,000 CyclesRated mating life
4 PinContact count
Technical Specifications
| Series | USB JACK |
| Type | Vertical plug-in / 4P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 4.0 kg MAX |
Key Features
- 13.2×6.9×H=13&13.7&15mm Vertical 4P (board-mounted plug-in) USB socket
Applications
- Consumer electronics
- USB peripherals and hubs
- Charging devices
- Industrial control equipment
Drawing & Dimensions
GSC-USA-0039 is a USB 4-contact connector, 13.2×6.9×H=13&13.7&15mm Vertical 4P (board-mounted plug-in) USB socket.
| Series | USB JACK |
|---|---|
| Type | Vertical plug-in / 4P |
| Mating cycles | 5,000 cycles |
| Insertion / Removal force | 4.0 kg MAX |
