USB Socket Waterproof USB Female Connector Micro USB Interface – GSC-USA-0089

USB Socket Waterproof USB Female Connector Micro USB Interface – GSC-USA-0089

USBSMTWaterproof
Tags:
#PCB#Receptacle#SMT#USB Connector#USB Type-A#Waterproof
Share:LinkedInFacebookXWhatsAppEmail

GSC-USA-0089 is a USB connector, 9.8×4.2×7.0 mm, IPX7 waterproof rating (surface-mount type), Micro USB connector. GSCONN part GSC-USA-0089.

Request a Quote → Download Datasheet
WaterproofRated waterproof construction
Surface MountSMT termination
5,000 CyclesRated mating life

Technical Specifications

SeriesMICRO USB JACK
Mating cycles5,000 cycles
Insertion / Removal force8–20 N

Key Features

  • 9.8×4.2×7.0 mm
  • IPX7 waterproof rating (surface-mount type)
  • Micro USB connector

Applications

  • Consumer electronics
  • USB peripherals and hubs
  • Charging devices
  • Industrial control equipment
Drawing & Dimensions
USB Socket Waterproof USB Female Connector Micro USB Interface – GSC-USA-0089 drawing

GSC-USA-0089 is a USB connector, 9.8×4.2×7.0 mm, IPX7 waterproof rating (surface-mount type), Micro USB connector.

Series MICRO USB JACK
Mating cycles 5,000 cycles
Insertion / Removal force 8–20 N

Downloads

Technical DrawingPDF · 59 KB
